精度precision

C

2

型號Model

J

J88

量程Range

kg

0.5~25

靈敏度Rated Output

mv/v

1.0/2.0±0.15

非線性Non-linearity

%F.S

0.05

滯后 Hysteresis

%F.S

0.05

重復性Repeatability

%F.S

0.05

蠕變Creep

%F.S/3min

0.05

溫度零點Temp.effect on zero

%F.S/10℃

0.05

溫度靈敏度Temp.effect on span

%F.S/10℃

0.05

零點輸出Zero balance

mv/v

±0.05

輸入阻抗Input impedance

Ω

405±10

輸出阻抗Output impedance

Ω

350±5

絕緣電阻Insulation resistance

MΩ

≥5000（50VDC)

推薦激勵電壓Recommended excitation voltage

VDC

3~10

溫度補償范圍Compensated temp.Range

℃

-10℃~+40℃

工作溫度范圍Operating temp.Range

℃

-20℃~+60℃

安全過載Safe overload

%F.S

120

極限過載Ultimate Overload

%F.S

150

接線方法Connection

Excitation:    Red: E+    Black:E -

Signal:        Green:S+   White:S-
